Tweeter

0.75" (20mm) Silk soft dome

1" (25 mm) Silk soft dome

1" (25mm) Slik soft dome

Woofer

5"(125 mm)GraphiteCone,RubberSurround

6.5" (165 mm)GraphiteCone,RubberSurround

8" (165 mm) Graphite Cone, Rubber Surround

FrequencyRange+/-3

65 Hz -20k Hz

45 Hz -20k Hz

65 Hz -20k Hz

Power Handing RMS

60 W program , 30 W ( IEEE 219 )

80 W program , 40 W ( IEEE 219 )

80 W program , 40 W ( IEEE 219 )

Sensitivity

84 dB

86 dB

86 dB

Taps

N/A

N/A

8Ω,0,40W,20W,10W,5W

Impedance

8 ohms

8 ohms

8 ohms

Termination

Standard pressed connector

Standard pressed connector

Pluggable Terminal Blocks

IncludedAccessories

Cuout template grille

Cuout template grille

Cuout template grille

Dimensions

4.09" x 7.75" (104mm x 197mm )

4.44" x 9.17" (113mm x233mm)

9.01" x 10.11" (229mm x 257mm)

Cut out diameter

6.73" (171mm)

8.11" (206mm)

8.85" (225mm)

Certifications

N/A

N/A

N/A

Attachment

Low-prfile grill

Low-prfile grill

Low-prfile grill
